Specifications:
Weight Capacity 44,000lbs. (22 Ton)
Min. Saddle Height 8-1/4″ (210mm)
Max. Saddle Height 17-3/4″ (450mm)
Hydraulic Lift 4-4/2″ (115mm)
Chassis Length 22″ (560mm)
Chassis Width 6-7/8″(176mm)
Height with Handle 50-1/2″ (1283mm)
Average Air Consumption 9.3cfm
Net Weight 117lbs. (53kg)
Compact and portable
Large 7-3/4″ diameter hard rubber tires make maneuverability easier
Includes quick springs for fast ram retraction – eliminates manual lowering of jack
Safety overload system prevents jack from being used beyond its rated capacity
Extension screw gives added height when necessary
Jack release valve is top mounted at “T” handle and allows jack operation at any handle position
Handle locking lever secures handle in either vertical or horizontal position
Long “T” handle helps in positioning jack under vehicles with long overhang
Rust inhibitive coating on ram and extension screw
MEETS ANSI STANDARD FOR PERFORMANCE AND SAFETY
