Parts List
| Item | Part No. | Qty. | |
| 1 | 12713 | Seal Assembly | 1 |
| 2 | 12901 | SS Rear Bracket Washer | 4 |
| 3 | 12717 | O-Ring for Screw Head | 4 |
| 4 | 13712 | Body Assembly | 1 |
| 5 | 13702 | Poly Pump Volute | 1 |
| 6 | 13771 | 4 Vane Impeller | 1 |
| 7 | 12705 | Check Valve | 1 |
| 8 | 12774VA | Impeller Bolt Gasket | 1 |
| 9 | 12900 | SS Upper Volute Screw | 4 |
| 10 | 12725 | SS Volute Screws | 2 |
| 11 | 12719A | Body O-Ring | 1 |
| 12 | 12754 | O-Ring Segment | 1 |
| 13 | 12720 | SS Body Screws | 10 |
| 14 | V07018 | SS Lock Washers | 10 |
| 15 | V07019 | SS Body Nuts | 10 |
| 16 | 12902A | Impeller Key | 1 |
| 17 | 13777 | Prime/Drain Plug | 2 |
| 18 | 13778 | Prime/Drain Plug O-Ring | 2 |
| 19 | 12703A | Poly Pump Rear Bracket | 1 |
| 20 | 12710 | O-Ring for Seal Assembly | 1 |
| 22 | 12715A | SS Bracket Screws | 4 |
| 23 | 15751 | Rear Bracket Shim | 1 |
| 24 | 12716 | Poly Pump Slinger | 1 |
| 25 | 12775A | Impeller Hex Nut | 1 |
