FEATURES:
- Three-zone design for longer life and true bi-directionality
- Bearings that meet the highest standards of the industry
- Options to optimize performance in every application
- Integrated crossover relief valve option
- Two-bolt flange: SAE A with 3-1/4″ pilot diameter
- Case drain: 7/16″-20 UNF-2B O-ring port size 4
SPECIFICATIONS:
| ACTUAL MOUNTING FLANGE: | 2-Bolt Flange – Sae A – With 3-1/4 In. Pilot Dia. |
| ACTUAL OUTPUT SHAFT: | Straight |
| ACTUAL PORT TYPE: | .875-14 UNF-2B SAE O-Ring Ports – Staggered Ports |
| CONTINUOUS FLOW RATE: | 75 L/min |
| DISPLACEMENT: | 6.20 in³/r |
| DRAIN CONNECTION SIZE: | .4375-20 Unf-2b O-ring Port Size -4 |
| INTERMITTENT PRESSURE: | 310 bar |
| MAX CONTINUOUS OIL VISCOSITY: | 70 Saybold universal second |
| MAX OPERATING TEMPERATURE: | 180 °F |
| MAXIMUM RPM-CONTINUOUS: | 477 rpm |
| MOUNTING TYPE: | 2-Bolt Flange – 3.25 in Pilot – SAE A |
| OPERATION RATING DESCRIPTION: | Continuous Rating – Motor May Be Run Continuously At These Ratings. / Intermittent Operation – 10 Percent Of Every Minute / Peak Operation – 1 Percent Of Every Minute |
| OUTPUT SHAFT SIZE: | 1 in Straight – Woodruff Key |
| PRODUCT HEIGHT: | 6.96″ |
| PRODUCT LENGTH: | 9.54″ |
| PRODUCT WIDTH: | 5.16″ |
| PORT CONFIGURATION: | .875-14 UNF-2B SAE O-Ring Ports – Staggered Ports |
| PORT ORIENTATION: | Staggered Ports |
| SEAL TYPE: | Standard |
| SERIES: | 2000 – Standard |
| SHAFT TYPE: | Straight |
