Copeland White-Rodgers 586-105111 586 Series 12A D.C. Contactor
Single Pole Normally Open Contacts. Water Resistant and Case is Isolated from Bracket
FEATURES:
- Double-make or double-break contacts
- Capable of handling high and low current requirements.
- Impact resistant phenolic casing
- Water and Dust Resistant Case Design
SPECIFICATIONS:
- Dielectric Strength: 500 volts
- Temperature Range: -40°F/-40°C to 149°F/65°C
- Mechanical Life (no load): 100,000 operations
- Electrical Life (rated load–making and breaking 200 amp on NO contacts): 50,000 cycles
- Mounting Position: Recommended mounting is vertical plane with coil
terminals up - Weight (approximate): 24.0 oz.
- Duty Cycle:
- Continuous
- Intermirrent: 10 seconds “on” maximum and minimum
60 seconds “off”; One minute “on” maximum and minimum 6 minutes “off”
- Hardware Torque Specification
- Contact Terminal: 60 inch-lbs. max.
- Coil Terminal: 12-18 inch-lbs
- Contacts
- Pole form: SPNO
- Material: silver alloy
- Termination: 5/16- 24 UNF-2A thread
- Volts DC: 12
- Continuous Contact Rating: 200A
- Inrush: 600A
- Termination: 10-32 UNF-2A thread
- Connections: Coil isolated (two terminals)
- Minimum operating voltage:
- 75% of rated coil voltage
- Maximum 10% over rated coil voltage
