Standard Features
- cULus listed to ULC/ORD-C842 – Valves for Flammable and Combustible Liquids (See details below in Code Compliance)
- 165° F fusible link activates spring closure
- 1/2″, 3/4”, or 1” female NPT threaded connections
- Compact size reduces operational footprint requirement
- Easy to install and maintain
Optional Criteria
- Operating pressure rated at 50 psi
- Operating temperature range rated at -20° F to 125° F
Construction Details
- Body: 316 stainless steel
- Cap, shaft, tail fitting, poppet, and nut: 303 stainless steel
- Lever arm: 304 stainless steel
- Handle: 356-T6 aluminum
- Spring: 17-7 stainless
- O-ring and disc: FKM
Code Compliance
cULus listed to ULC/ORD-C842
